Description

Features

• Rotating Olympic handle insures easy release and reset of bar with each set
• Enhanced biomechanics with a 7 degree angle for squatting and pressing motions
• Counterbalanced Olympic bar with 12lbs (5.5kg) take off weight for all user levels
• Adjustable red safety catches to insure proper execution of all exercises
• Six, marked weight storage pegs per side to accommodate all plate increments
• Rubber feet for floor protection

ADJUSTMENTS & MOVEMENTS

• User Defined Range of Motion: Yes, enhanced biomechanics with a 7 degree angle for squatting and pressing motions
• Assisted Adjustments: Yes, Gravity assisted positioning
• Color Coded Pivot Points and Adjustments: Yes
• Unilateral or Bilateral Movement: N/A
• Converging or Diverging Movements: N/A
• Pulley Ratio: N/A

FRAME SPECIFICATIONS & CABLE INFORMATION

• Standard Frame Color Options: Matte Black (-60)
• Standard Upholstery Color Options: N/A
• Frame Finish: Electrostatic Powder coating
• Customizable Paint Options Available: Yes with additional fees and extended lead times
• Customizable Upholstery Options Available: N/A
• Customizable Branding Options Available: No
• Cable Vs. Belt Driven Transmission: N/A
• Bolt Down Locations Defined: Yes
• Integrated Leveling System: No, rubber feet for floor protection
• Hardware Type: Hex / Button Head
• Tubbing Style & Thickness: Modern blend of square and round tubing. Most are 3 or 2.5mm / 11 ga

USER SPECIFIC INFORMATION

• Static Placards: No
• Multi-Language Placards Options Available: N/A
• Animated Lenticular: No
• Safety Catch & Stops: Adjustable red safety catches to insure proper execution of all exercises
• Water Bottle Holder: No
• Phone Holder: No
• Grip Specifications: Rubber, smaller grips.
• Foot Platform: N/A
• Contoured Pads: N/A
• Restraint System: Rotating Olympic handle insures easy release and reset of bar with each set & adjustable red safety catches to insure proper execution of all exercises

WEIGHT STACK SPECIFICATIONS

• Total Stack Weight: N/A
• Incremental Weight System: N/A
• Weight Stack Tower Height: N/A
• Plate Loaded: Counterbalanced Olympic bar with 12 lb (5.5 kg) starting resistance
• Weight Storage Solution: Six, marked weight storage pegs per side to accommodate all plate increments
• LNL Technology: N/A
• Add-On Resistance Available: Yes, max load capacity 8-45 lb (20 kg) plates per side
• Weight Stack Shroud Specifications: N/A

Tech Specs

• Dimensions: 67"L x 89"W x 82"H (L:170cm, W:226cm, H:208cm)
• Stack Weight: N/A
• Overall Weight: 648 lb (294 KG)
• Shipping Weight: 794 lb (360 KG)

Warranty & Compliance

• California Residents see Prop 65 WARNING

• COMMERCIAL (Facilities that charge dues and/or > 8 hours/day usage)

  Limited 10 year warranty on structural frame not including coatings, 5 years parts on major mechanical components - guide rods, plates, bearings, etc. 1 year on minor mechanical components - plate switches, cables, grips, etc. 6 months on upholstery, 1 year labor.



  LIGHT COMMERCIAL/VERTICAL (Non-dues paying facility and < 8 hours/day usage)

  Limited 10 year warranty on structural frame not including coatings, 5 years parts on major mechanical components - guide rods, plates, bearings, etc. 3 years on minor mechanical components - plate switches, cables, grips, etc. 6 months on upholstery, 3 years labor.



  CONSUMER (Home setting, equipment used by home occupants only.)

  Limited 10 year warranty on structural frame not including coatings, 10 years parts on major mechanical components - guide rods, plates, bearings, etc. 10 years on minor mechanical components - plate switches, cables, grips, etc. 6 months on upholstery, 3 years labor.
