Overview

• Total body conditioning of the cardiovascular and muscular systems
• Use arms alone, legs alone, or both
• Closed-kinetic chain exercise
• Low 9.5"-13.5" step-through height for easy access
• Biomechanically correct workout position
• Contralateral movement arm linked with opposite leg
• Smooth, fully connected motion between arms and legs
• User-controlled step length of 2" - 8.5"

Resistance System

• Quiet, frictionless, permanent magnetic eddy current system with 10 workload levels
• User power output from 0-800 watts
• All-belt drive
• Long-life, high-grade bearings

Frame

• Durable, heavy-duty welded steel frame
• Powder-coated frame and zinc-plated components resist rust
• Four-point contact with the floor and leveling feet increase stability
• Strong, impact-resistant poly-styrene cover is easy to clean
• Lift unit with front handle and roll on rear wheels or user optional NuStep transporter device

Arms

• Anodized aluminum arms with extra-long, comfortable hand grips
• Ergonomically correct hand position
• Long, 15" arm adjustment range

Seat and Arm Rests

• Swivel seat rotates 360° and locks at 45° increments
• Foam-covered seat and swivel release levers work from front, sides or back
• Seat slides and adjusts smoothly
• 15" forward/backward seat adjustment range
• Ergonomically designed padded seat has contoured back support.

Display

• Simple, one-button quick start and reset; automatic power on/off
• Easy-to-read display shows:
• SPM: 5-210
• Watts: 5-800
• METS: 2-24
• Time: Starts at 0:00, counts up
• Steps: Counts cumulative steps up to 9999
• Distance: MI or Km
• Load levels: 10 load levels
• Calories: Up to 999 KCal
• User selects English or metric measurement system
• Optional Polar® transmitter belt enables heart rate display on console
• Cordless design uses 4 AA alkaline batteries
  (NiMH rechargeable batteries may also be used).
• USB port for data download

Foot Pedals

• Pedals are made of durable molded plastic
• Four-bar linkage and nonskid tread keep feet secure
