Description

Features

• Cables: 7x19 strand construction, lubricated, nylon-coated cable meets U.S. military specifications
• Instructional Placards: Easy-to-follow instructions illustrate proper use and muscles trained; Axis of rotation marked with red indicator to help cue correct alignment
• Belts and Pulleys: 4-1/2" (11 cm) and 6" (15 cm) diameter fiberglass-impregnated nylon pulleys feature sealed bearings
• Cushioning: Pads are molded with radius on edge for improved comfort; All edges are stitched to eliminate any folds in the material that would limit durability
• Shrouds: Standard rear shroud on SE models; Optional full front shroud on SE models
• Weight Plates and Guide Rods: Solid-steel weight plates. Top weight plate is fitted with self-lubricating bushings; 7/16" (11 mm) diameter weight selector pin magnetically locks in place and is connected to stack to prevent loss; Drop down incremental weight system (standard on SE models)
• Adjustments: Roller mechanism on seat adjustment provides smooth operation
• Foot Platforms: Polyethylene spray-coated for impact, corrosion, and abrasion resistance
• Frame Description: Each frame receives an electrostatic powder coat finish to ensure maximum adhesion and durability; Standard rubber feet protect base of the frame and prevent the machine from slipping; 11-gauge steel frame ensures maximum structural integrity
• Hand Grips: Grips retained with aluminum collars, preventing them from slipping during use; Hand grips are an extruded thermo rubber compound that is non-absorbing and wear-and-tear resistant

Tech Specs

• Dimensions: 46"L x 45"W x 87"H (metric cm: 118 x 113 x 221)
• Recommended Live Area: 70" x 45" x 87" (metric cm: 178 x 113 x 221)
• Weight Stack(s): 175 lb (82 kg)
• Max User Weight: 300 lb (136 kg)
• Weight: 655 lb (298 kg)

Warranty & Compliance

• 1 Year Parts & Labor Warranty Standard
• Extended Warranty Options up to 5 Years Parts & Labor Available: See Product Warranty Options for Pricing

• California Residents see Prop 65 WARNING
