Arm pad

• Configured to align elbows off pad in order to reduce joint compression and extend pad life

Frame

• Constructed primarily of U.S. manufactured 2" (5 cm) sq 11-gauge wall thickness steel tubing
• Each part is sandblasted prior to finish to prepare the surface for maximum adhesion
• Epoxy powder coat finish

Weight Stack

• Solid steel weight plates
• Top weight plate is fitted with self-lubricating and self-cleaning bushings
• Low-friction bushings contained in each plate eliminate metal-to-metal contact between plates and guide rods
• 7/16" (1 cm) diameter weight selector pin magnetically locks in place and is connected to stack to prevent loss
• Shock-absorbing durable rubber bumpers under each stack reduce vibration
• Weight stack is guarded on back to prevent inadvertent contact during use

Seat And Lever - Arm Adjustment

• Most units use a Quick ClickTM ratcheting seat adjust system which adjusts in 1/2" (1 cm) increments
• Some back pad adjustments are spring-loaded, adjusting from the exercise position
• No metal-to-metal contact reduces friction for easier adjustment and increased life
• Lever-arm adjusters use a patent pending four-bar linkage mechanism and adjust in three positions

Cable And Pulleys

• 7 x 19 strand construction, lubricated, nylon-coated cable with breaking strength rated at 4200 lbs (1909 kg)(meets U.S. military specifications)
• Consistent cable tension adjustment located on top weight; only two standard 3/4" (2 cm) open-ended wrenches required
• 4 1/2" (11 cm) and 6" (15 cm) diameter fiberglass-impregnated nylon pulleys with sealed bearings
• Interface between cable and pulleys are guarded with covers
