Nautilus Instinct Lat Pull Down 9NL-S3310-60ARS (New)

Nautilus Instinct Lat Pull Down 9NL-S3310-60ARS (New)

Available to Order
As high as: USD $4,149.00
$3,499.00
$3,499.00
You save $650.00
Nautilus Instinct Lat Pull Down 9NL-S3310-60ARS Image
Nautilus Instinct Lat Pull Down 9NL-S3310-60ARS (New)
Nautilus Instinct Lat Pull Down 9NL-S3310-60ARS (New)
Nautilus Instinct Lat Pull Down 9NL-S3310-60ARS (New)
Nautilus Instinct Lat Pull Down 9NL-S3310-60ARS (New)
Nautilus Instinct Lat Pull Down 9NL-S3310-60ARS (New)
Nautilus Instinct Lat Pull Down 9NL-S3310-60ARS Image
Nautilus Instinct Lat Pull Down 9NL-S3310-60ARS (New)
Nautilus Instinct Lat Pull Down 9NL-S3310-60ARS (New)
Nautilus Instinct Lat Pull Down 9NL-S3310-60ARS (New)
Nautilus Instinct Lat Pull Down 9NL-S3310-60ARS (New)
Nautilus Instinct Lat Pull Down 9NL-S3310-60ARS (New)
Condition: New
Grade: Commercial (More Info)
Warranty: Full Manufacturers (More Info)
Ships: New in Manufacturers Packaging (Assembly Options Available)
Processing Time: Ships from Manufacturer's Warehouse in 1-2 Weeks (More Info)
Product Code: NAU-9NLS331060ARS

Colors

Paint Color
Vinyl Color
Upholstery Color
Total with options

$3,499.00

As low as $XXX / 4 interest-free payment
View full details

Interested in a closer look?

Schedule a video call with us!

Contact us

Description

EASY TO USE. EASY ON SPACE.

When it comes to a complete workout, it’s all business. Whether you’re an experienced athlete or a beginner, everyone wants the ability to get a quick, easy and complete workout. And that’s exactly what Instinct® Strength is all about. Each piece welcomes users of all levels with quick and easy adjustments for efficient workouts. Perfectly suited to be a basic strength line or circuit system, Instinct effectively complements more specialized lines. Users can complete a circuit on their own or with the assistance of an instructor in just 30 minutes. Instinct® Strength offers both single and dual function units to meet the needs of any space or facility. Instinct also offers the revolutionary Lock N Load® patented weight selection system. The versatility of Instinct’s small footprint also lets you get the most from minimal space, while blending seamlessly with our cardio line for a cohesive facility look.

Extra info

Manuals

Photos

Features

  • Brand: Nautilus
  • Simple, intuitive placard
  • Removable wear strap for extended upholstery life
  • Adjustable seat with “easy up” ratcheting adjustment
  • Adjustable thigh support stabilization pad
  • Rubber feet for floor protection
  • Multi-position hand grips
  • Kevlar transmission belt for extended life and easy replacement
  • Featuring the patented Lock N Load® weight selection system
ADJUSTMENTS & MOVEMENTS
  • User Defined Range Of Motion: Fixed path
  • Assisted Adjustments: Gravity assisted seat bottom
  • Color Coded Pivot Points And Adjustments: Yes on all units
  • Unilateral Or Bilateral Movement: Possible if user uses one handle at a time
  • Converging Or Diverging Movements: Linear motion
  • Pulley Ratio: 1:1
FRAME SPECIFICATIONS & CABLE INFORMATION
  • Standard Frame Color Options: Silver, White, Black
  • Standard Upholstery Color Options: Dove Gray, Black
  • Frame Finish: Electrostatic Powder coating
  • Customizable Paint Options Available: Yes with additional fees and extended lead times
  • Customizable Upholstery Options Available: Yes with additional fees and extended lead times
  • Customizable Branding Options Available: Yes with additional fees and extended lead times
  • Cable Vs. Belt Driven Transmission: Belt
  • Bolt Down Locations Defined: Yes
  • Integrated Leveling System: No, rubber feet for floor protection
  • Hardware Type: Hex / Button Head
  • Tubbing Style & Thickness: Modern blend of square and round tubing. Most are 3 or 2.5mm / 11 ga
USER SPECIFIC INFORMATION
  • Static Placards: Yes, simple and intuitive placard
  • Multi-Language Placards Options Available: Large and graphical, limited text to eliminate translation requirements
  • Animated Lenticular: No
  • Safety Catch & Stops: N/A
  • Water Bottle Holder: No
  • Phone Holder: No
  • Grip Specifications: Rubber, large grips for pushing, smaller grips for pulling
  • Foot Platform: N/A
  • Contoured Pads: No, removable wear strap for extended upholstery life
  • Restraint System: N/A
Lock N Load
Selecting a weight with the intuitive Lock N Load design is as easy as flicking a switch. Universally color coded switches engage and disengage the weight via an internal pin, providing a safer, more durable and maintenance free operation. Lock N Load prevents unnecessary maintenance headaches since there are no pins to lose or replace.
DUAL USE MACHINES
The versatile dual purpose machines from Nautilus Instinct have a modest footprint and allow you to switch between two different exercises with a simple adjustment. This is ideal for smaller facilities, giving them the ability to fit a full fitness circuit in a much smaller space.

Tech specs

  • Dimensions: 60"L x 47"W x 73"H (L:152 cm, W:119 cm, H:185 cm)
  • Stack Weight: 235 lb (107 KG)
  • Overall Weight: 515 lb (234 KG)
Equipment Customization Options

Tailored solutions at your fingertips. Reach out to us for pricing details and estimated delivery times (ETA).

Frame Color Options



*Customization colors shown here are approximations. Physical paint colors may vary.

Upholstery Options



Logo Placement Examples (Placement and production style vary by product)

Weight Stacks

  • Total Stack Weight: 235 lb (107 KG)
  • Incremental Weight System: 5/10/15, 235
  • Weight Stack Tower Height: 57 in (145 cm)
  • Plate Loaded: N/A
  • Weight Storage Solution: N/A
  • Lnl Technology: Yes
  • Add-On Resistance Available: No
  • Weight Stack Shroud Specifications: Transparent, smoked plexiglass inside and outside shrouds

Shipping Dims & Weight

  • Shipping Weight: 584 lb (265 KG)

Warranty

  • COMMERCIAL (Facilities that charge dues and/or > 8 hours/day usage): Limited 10 year warranty on structural frame not including coatings, 5 years parts on major mechanical components - guide rods, plates, bearings, etc. 1 year on minor mechanical components - plate switches, cables, grips, etc. 90 days on upholstery, 1 year labor.
  • LIGHT COMMERCIAL/VERTICAL (Non-dues paying facility and < 8 hours/day usage): Limited 10 year warranty on structural frame not including coatings, 5 years parts on major mechanical components - guide rods, plates, bearings, etc. 3 years on minor mechanical components - plate switches, cables, grips, etc. 90 days on upholstery, 3 years labor.
  • CONSUMER (Home setting, equipment used by home occupants only.): Limited 10 year warranty on structural frame not including coatings, 10 years parts on major mechanical components - guide rods, plates, bearings, etc. 10 years on minor mechanical components - plate switches, cables, grips, etc. 90 days on upholstery, 3 years labor

California Residents see Prop 65 WARNING
